How does reverse iteration create a V-shaped pattern?

Program 7 runs i from 1 to rows (inverted V: narrow top, wide bottom). Program 8 runs i from rows down to 1 with the same inner loops, so the first line uses i equal rows and prints stars at j equals rows and k equals rows. As i decreases, both legs move inward until the last line has i equal 1: one star from the j loop at j equals 1 and only spaces from the k loop (k starts at 2), giving an upright V with the vertex at the bottom.

What is the time complexity of this V-shaped hollow star pattern program?

With n rows, each row does Theta(n) iterations across the two inner loops, so the time complexity is Theta(n²), i.e. O(n²).

V-Shaped Hollow Star Pattern in C++

Q: What is the difference between this pattern and Program 7?

Only the outer loop direction changes. Program 7 uses i from 1 to rows (inverted V). Program 8 uses i from rows to 1 (upright V). The conditions i equals j and i equals k are the same.

Q: Why does the bottom row show only one star?

When i is 1, the first inner loop still prints a star at j equals 1. The second loop runs k from 2 to rows, so i equals k never holds. The right leg does not add a second star on that row; you still get trailing spaces so the line width stays 2 times rows minus 1 characters.

Beginner

⏱️ 7 min read

📚 Updated: Aug 2025

🎯 2 Code Examples

n rows total

V-shaped hollow star pattern (wide top, vertex at bottom) in C++

What You'll Learn

This program prints a hollow V (two stars on the first row, then closer together each row until one star on the last row). See Program 7 for the inverted V (narrow top, wide base). This page’s pattern is the lower half of the hollow diamond (Program 9).

Each line has width 2 * rows - 1 (9 characters when rows = 5), including spaces used for alignment.

⭐ Pattern Output

When you run the program with rows = 5:

Output

Complete C++ Program

Fixed rows = 5 version:

C++

#include <iostream>
using namespace std;

int main() {
    int rows = 5;
    int i, j, k;

    for (i = rows; i >= 1; --i) {
        for (j = rows; j >= 1; --j) {
            if (i == j) cout << "*";
            else cout << " ";
        }
        for (k = 2; k <= rows; ++k) {
            if (i == k) cout << "*";
            else cout << " ";
        }
        cout << "\n";
    }

    return 0;
}

🧠 How It Works

Outer loop: wide row first

for (i = rows; i >= 1; --i) prints the opening row with two outer stars, then closes toward the bottom vertex. Same j/k structure as the inverted V, reversed i order.

Outer

Left leg (`j`)

for (j = rows; j >= 1; --j) with if (i == j) cout << "*"; else cout << " "; draws the left diagonal.

Left

Right leg (`k`)

for (k = 2; k <= rows; ++k) with the same conditional. For i == 1 only the j loop emits the single bottom star.

Right

Newline & width

cout << "\n" after both segments. Line length stays 2 * rows - 1 for a stable silhouette.

Width

Hollow V

O(rows²) character writes, O(1) extra space. Combine with the inverted-V half to form a hollow diamond. Wide rows scroll in the green glyph on phones.

Variation — User Input Version

Accept rows with cin:

C++

#include <iostream>
using namespace std;

int main() {
    int rows;
    int i, j, k;

    cout << "Enter the number of rows: ";
    cin >> rows;

    for (i = rows; i >= 1; --i) {
        for (j = rows; j >= 1; --j) {
            if (i == j) cout << "*";
            else cout << " ";
        }
        for (k = 2; k <= rows; ++k) {
            if (i == k) cout << "*";
            else cout << " ";
        }
        cout << "\n";
    }

    return 0;
}

💡 Tips for Enhancement

Try These

Switch the outer loop to 1..rows to recover Program 7 (inverted V)
Validate rows >= 1 after input
Stack Program 7 (inverted V) then Program 8 (upright V), or see Program 9 for the full hollow diamond
Print row index i where stars appear

Avoid

Claiming two stars on the bottom row from both loops—only j hits i == 1
Incrementing i in the outer loop (that produces Program 7’s inverted V, not this upright V)
Omitting spaces so columns no longer align

Key Takeaways

Same inner logic as Program 7 (inverted V); only outer loop direction changes to flip the shape upright.

Top row (i == rows): stars at j == rows and k == rows.

Bottom row (i == 1): one star from j; k loop is all spaces.

Line width remains 2 * rows - 1 characters.

Time complexity O(n²) for n rows.

❓ Frequently Asked Questions

How does reverse iteration create a V shape?

Large i values run first, so the row with two outer stars (i == rows) is printed before smaller i values pull the legs inward.

What is the difference between this pattern and Program 7?

Program 7 uses for (i = 1; i <= rows; ++i) (inverted V, narrow top). Program 8 uses for (i = rows; i >= 1; --i) (upright V, vertex at bottom). The j and k loops and the if conditions are the same.

Why does the bottom row show only one star?

For i == 1, the right loop only considers k >= 2, so i == k never holds. The bottom vertex is the lone * from j == 1, plus padding spaces to the right.

What is the time complexity of this program?

O(n²) for n rows, same as Program 7.

Next: Hollow Diamond Pattern

Continue to Program 9 to combine the upper and lower halves into a hollow diamond.

Program 9 →

Did you know?

If you start the same descending row loop at rows - 1 (instead of rows), you get the lower half of the hollow diamond without printing the middle row twice.
