C++ Hollow Diamond Star Pattern (Inside Square)

Beginner
8 min read
Updated: Sep 2026
3 programs
Live preview
Hollow diamond inside square frame star pattern output in C++ programming
Definition

What Is This Pattern?

A hollow diamond inside a square frames a hollow diamond with solid top and bottom bars: every line is 2 * rows characters wide, and height is 2 * rows - 1.

Remember
Rule: solid bars on ends; elsewhere left * + gap + right *

**********
****  ****
***    ***
**      **
*        *
**      **
***    ***
****  ****
**********     ← rows = 5 (width 10, height 9)

Unlike Program 9 (hollow diamond alone) or Program 10 (filled diamond), middle rows here are always left stars, gap spaces, then left stars again — with a mirrored i so the hollow opens to the waist and closes again.

Approach

How to Solve It

Two ways to emit the same shape — start with segment loops, then optionally shorten with a helper.

MethodIdeaBest for
Three-segment loopsSolid bars on ends; left / gap / right insideLearning, interviews, exams
print_chars helperBuild each bar or segment in one callShorter demos once formulas click

Pseudocode

Pseudocode
height = 2 * rows - 1
width  = 2 * rows

for line from 1 to height:
    if line is first or last:
        print width stars
    else:
        i = line if line <= rows else (2 * rows - line)
        left = rows - i + 1
        gap  = 2 * (i - 1)
        print left stars, gap spaces, left stars
    print newline

Cheat sheet

GoalPattern
Dimensionsheight = 2 * rows - 1, width = 2 * rows
Solid barif (line == 1 || line == height) print width stars
Map line → ii = (line <= rows) ? line : (2 * rows - line)
Left / right starsleft = rows - i + 1
Hollow gapgap = 2 * (i - 1)
Width check2 * left + gap == width
Helper shortcutprint_chars('*', width); cout << "\n";

Printing Stars vs Starting a New Line

APIEffectUse for
cout << "*" / " "Stays on the same lineEach star and each space
cout << "\n"Ends the current lineAfter the bar or the three segments
Try it

Live Preview

Change the size and the framed hollow diamond updates instantly — including width and height.

Whole numbers from 1 to 10. Width is 2 * rows; height is 2 * rows - 1.

Live result 5 rows · 10×9
**********
****  ****
***    ***
**      **
*        *
**      **
***    ***
****  ****
**********
Trace

Worked Walkthrough — rows = 4

Trace each line: solid bar or inner row with i, left, and gap. Grid size: width 8, height 7.

lineKindileftgapPrinted row
1Bar———********
2Inner232*** ***
3Inner324** **
4Inner416* *
5Inner324** **
6Inner232*** ***
7Bar———********

On every inner row, 2 * left + gap = 8 = width. Lines 3 and 5 share the same i because of mirroring — that is why time is still O(n²).

Code

C++ Programs

Three complete programs: fixed size, console input, and a print_chars helper. Use View Output to reveal sample results.

Example 1 — Fixed rows = 5

Hard-coded size — solid bars on the ends; left / gap / right on every other line.

C++
#include <iostream>
using namespace std;

int main() {
    int rows = 5;
    int height = 2 * rows - 1;
    int width = 2 * rows;

    for (int line = 1; line <= height; ++line) {
        if (line == 1 || line == height) {
            for (int j = 1; j <= width; ++j) {
                cout << "*";
            }
        } else {
            int i = (line <= rows) ? line : (2 * rows - line);
            int left = rows - i + 1;
            int gap = 2 * (i - 1);

            for (int j = 1; j <= left; ++j) {
                cout << "*";
            }
            for (int j = 1; j <= gap; ++j) {
                cout << " ";
            }
            for (int j = 1; j <= left; ++j) {
                cout << "*";
            }
        }
        cout << "\n";
    }

    return 0;
}

How It Works

1. Set the grid. height = 9 and width = 10 for rows = 5.

2. Solid bars. When line is 1 or 9, print ten stars with cout.

3. Map the inner index. For other lines, i = line on the way down, or 2 * rows - line on the way up.

4. Print three segments. left stars, gap spaces, left stars — then cout << "\n".

On the waist (line = 5), i = 5, so left = 1 and gap = 8: one star on each side with a wide hollow center.

Example 2 — User Input Version

Read the size at runtime. Check cin.fail() in real apps (shown in the tip below).

C++
#include <iostream>
using namespace std;

int main() {
    int rows;

    cout << "Enter the number of rows: ";
    cin >> rows;

    int height = 2 * rows - 1;
    int width = 2 * rows;

    for (int line = 1; line <= height; ++line) {
        if (line == 1 || line == height) {
            for (int j = 1; j <= width; ++j) {
                cout << "*";
            }
        } else {
            int i = (line <= rows) ? line : (2 * rows - line);
            int left = rows - i + 1;
            int gap = 2 * (i - 1);

            for (int j = 1; j <= left; ++j) {
                cout << "*";
            }
            for (int j = 1; j <= gap; ++j) {
                cout << " ";
            }
            for (int j = 1; j <= left; ++j) {
                cout << "*";
            }
        }
        cout << "\n";
    }

    return 0;
}

How It Works

1. Prompt and read. Ask for a size, then store it with cin >> rows.

2. Same grid core. Only the source of rows changes — the bar and left/gap/right logic matches Example 1.

3. Safer input tip. Bad input sets cin’s fail bit. Prefer:

Safer input
if (!(cin >> rows) || rows < 1) {
    cout << "Enter a positive whole number.\n";
    return 1;
}

Example 3 — print_chars Helper

Build the solid bar and each left / gap / right piece with one helper — same shape, fewer inner loops.

C++
#include <iostream>
#include <string>
using namespace std;

void print_chars(char ch, int n) {
    cout << string(n, ch);
}

int main() {
    int rows = 5;
    int height = 2 * rows - 1;
    int width = 2 * rows;

    for (int line = 1; line <= height; ++line) {
        if (line == 1 || line == height) {
            print_chars('*', width);
            cout << "\n";
        } else {
            int i = (line <= rows) ? line : (2 * rows - line);
            int left = rows - i + 1;
            int gap = 2 * (i - 1);

            print_chars('*', left);
            print_chars(' ', gap);
            print_chars('*', left);
            cout << "\n";
        }
    }

    return 0;
}

How It Works

1. Same outer loop. Still walk line from 1 to height with the same bar vs inner branch.

2. Build each segment. print_chars('*', left) and print_chars(' ', gap) replace the character loops.

3. Print and advance. Call cout << "\n" after the bar or the three segments so the row ends correctly.

Learn the loop version first (Examples 1–2) so you can explain every bound in an interview; treat this as a polish shortcut afterward.

Edge Cases & Pitfalls

Check these before calling the solution done.

Width vs height

Do not swap formulas

Width is 2 * rows; height is 2 * rows - 1. Mixing them skews the whole frame.

Wrong mirror

Broken lower half

Use i = (line <= rows) ? line : (2 * rows - line). Forgetting the mirror breaks symmetry.

Program 9 logic

Different layout

Diagonal i == j tests from Program 9 do not draw this framed figure — use left / gap / right.

rows = 1

Single bar

Height = 1, width = 2 — output is just ** (first line is also the last).

rows ≤ 0

Empty output

Outer loop never runs. Validate and re-prompt for interactive programs.

Bad input

Check cin.fail()

Letters leave cin in a failed state — prefer if (!(cin >> rows) || rows < 1).

Analysis

Time and Space Complexity

ProgramTimeExtra space
Nested loops (Examples 1–2)O(rows²)O(1)
print_chars helper (Example 3)O(rows²)O(rows) temporary per segment

About 2n - 1 lines × 2n characters per line for n = rows — still quadratic in n.

Remember

Key Takeaways

  • Grid: width 2n, height 2n - 1.
  • Bars: solid top and bottom; elsewhere left / gap / right.
  • Mirror: map line → i, then left = rows - i + 1 and gap = 2 * (i - 1).
  • Complexity: O(n²) time; O(1) extra space for nested loops.

One line: solid bars on the ends; elsewhere print left stars, gap spaces, left stars — keep 2 * left + gap == width.

Frequently Asked Questions

Use height 2*rows-1 and width 2*rows. Print a full row of stars on the first and last lines. For every other line, map line to i with symmetry, then print (rows-i+1) stars, a gap of 2*(i-1) spaces, and the same number of stars again.
Width is 2*rows and height is 2*rows-1 so the top and bottom are full horizontal bars while the sides close on the leftmost and rightmost columns of the inner rows.
Program 9 prints a hollow diamond alone with constant width 2*rows-1. Program 11 adds solid top and bottom bars of length 2*rows and builds each inner line from left stars, a gap, and right stars.
left = rows - i + 1 is how many stars sit on each side. gap = 2 * (i - 1) is the hollow space between them. Together they always sum to width.
If line <= rows, i = line. Otherwise i = 2 * rows - line. That mirrors the distance from the nearest end so the hollow waist is widest in the middle.
cout << "*" stays on the same line. cout << "\n" ends the current line. Stars and spaces use cout without a newline; the row break uses cout << "\n" after the bar or the three segments.
O(n²) where n is rows. There are 2n-1 lines and each prints 2n characters.
After cin >> rows, check cin.fail() and require rows >= 1 so bad input does not leave rows unset.

Did you know?

Every line is exactly 2 * rows characters wide. Inner rows always satisfy 2 * left + gap == 2 * rows — so the frame closes cleanly on both sides.
