Canvas Text

Beginner
⏱️ 10 min read
📚 Updated: Aug 2025
🎯 Live + 2 Examples
fillText / strokeText
Canvas text tutorial illustration showing filled and stroked text alignment

What You’ll Learn

Canvas can draw text directly onto the bitmap surface. You can fill text, stroke text, and control alignment/baselines for consistent layout.

Unlike HTML, canvas text does not wrap automatically—you control layout yourself (often using measureText()).

⚡ Quick Reference

Basic text
ctx.font = '700 32px Arial';
ctx.textAlign = 'center';
ctx.textBaseline = 'middle';
ctx.fillStyle = '#2563eb';

ctx.fillText('Hello, Canvas!', canvas.width / 2, canvas.height / 2);
Font font

CSS font string (size + family)

Align textAlign

left | center | right | start | end

Baseline textBaseline

top | middle | alphabetic | bottom…

Measure measureText()

Compute width for layout

👀 Live Preview — Font, Align & Outline

Change font size, alignment, and baseline. Toggle filled vs outlined text, and optionally set maxWidth (horizontal scaling only).

width: —

Tip: Use measureText() for layout. The maxWidth parameter does not wrap—it compresses text horizontally to fit.

1

Centered Filled + Stroked Text

This mirrors the legacy example: draw filled text and then an outlined version below it.

index.html
<canvas id="myCanvas" width="500" height="220"></canvas>
<script>
  const canvas = document.getElementById('myCanvas');
  const ctx = canvas.getContext('2d');

  ctx.font = '30px Arial';
  ctx.textAlign = 'center';
  ctx.textBaseline = 'middle';
  ctx.fillStyle = 'blue';
  ctx.strokeStyle = 'black';
  ctx.lineWidth = 2;

  ctx.fillText('Hello, Canvas!', canvas.width / 2, canvas.height / 2);
  ctx.strokeText('Hello, Canvas!', canvas.width / 2, canvas.height / 2 + 50);
</script>
2

Use measureText() for Layout

Measure text width after setting ctx.font and draw a background box that fits.

script.js
const text = 'Measured label';
ctx.font = '700 28px Arial';
const w = ctx.measureText(text).width;

const x = 40, y = 70, pad = 14;
ctx.fillStyle = 'rgba(37, 99, 235, 0.18)';
ctx.fillRect(x - pad, y - 28 - pad, w + pad * 2, 40 + pad);

ctx.fillStyle = '#0f172a';
ctx.textAlign = 'left';
ctx.textBaseline = 'alphabetic';
ctx.fillText(text, x, y);

💡 Best Practices

Do

  • Set font before calling measureText()
  • Use textAlign + textBaseline for predictable positioning
  • Combine fill + stroke for readable outlined text
  • Use consistent font strings (weight + size + family)
  • Cache rendered text to an offscreen canvas if drawing it repeatedly

Don’t

  • Expect automatic wrapping like HTML (canvas doesn’t wrap)
  • Rely on maxWidth for wrapping (it compresses horizontally)
  • Forget that transforms (scale/rotate) also affect text
  • Use huge stroke widths on small text (it becomes illegible)
  • Redraw complex text every frame without profiling

❓ Frequently Asked Questions

fillText() fills glyphs using fillStyle. strokeText() outlines glyphs using strokeStyle and lineWidth.
Set textAlign='center' and textBaseline='middle', then draw at the canvas center.
Call ctx.measureText(text).width after setting ctx.font.
It scales text horizontally to fit the width. It does not wrap onto multiple lines.

Next: Canvas Transform

Learn how transforms stack and how to combine them cleanly.

Canvas Transform →
